Can-am Maverick X3 X DS 64" OEM "Dualsport" OEM Replacement Suspension Kit

Can-am Maverick X3 X DS 64" OEM "Dualsport" OEM Replacement Suspension Kit

Code: MAV-05300
$3,499.99
In Stock

PART # MAV-05300

Can-AM Maverick X3 X DS 64" O.E.M. Replacement Suspension Kit. Fits 2 and 4 Seat Models.

To take the already impressive X3 one step further, HCR has developed an American - made product to look, feel and function better than factory. The HCR X3 suspension kit is designed as an OEM Factory replacement kit for the 64" X DS models. The HCR signature High Clearance A Arm and trailing arm design increases ground clearance 1.5 inches under key components. Approach angles have been improved for reduced surface attraction and friction.



MAV-05300 64" Suspension Kit includes: 4 Front A-arms (2 upper, 2 lower), 2 Rear Trailing Arms, Delrin Bushings for replacement in the front A-arms, brake line mounting hardware, and shock bolts.

Note: For this kit you will need to reuse or replace with OEM/aftermarket components: Ball joints in the front A-arms, Crush Sleeves and wear plates in the Front A-arms, Trailing arm Radial joints, mounting bolts and hardware otherwise not provided.

PART # MAV-05300

Can-AM Maverick X3 X DS 64" O.E.M. Replacement Suspension Kit. Fits 2 and 4 Seat Models.

To take the already impressive X3 one step further, HCR has developed an American - made product to look, feel and function better than factory. The HCR X3 suspension kit is designed as an OEM Factory replacement kit for the 64" X DS models. The HCR signature High Clearance A Arm and trailing arm design increases ground clearance 1.5 inches under key components. Approach angles have been improved for reduced surface attraction and friction.



MAV-05300 64" Suspension Kit includes: 4 Front A-arms (2 upper, 2 lower), 2 Rear Trailing Arms, Delrin Bushings for replacement in the front A-arms, brake line mounting hardware, and shock bolts.

Note: For this kit you will need to reuse or replace with OEM/aftermarket components: Ball joints in the front A-arms, Crush Sleeves and wear plates in the Front A-arms, Trailing arm Radial joints, mounting bolts and hardware otherwise not provided.

Who We Are

HCR's proprietary billet slot and tab design and catacomb boxed arms are built to withstand the vigorous beatings of off-road riding while achieving the optimal combination of strength and appeal. Every external weld is an internal plate structured into the design. All parts are Fiber laser cut and CNC bent for precise fit and finish. An intensive process is used during each design to simulate and refine the new geometry to match the characteristics of the stock suspension while increasing suspension travel. Critical measurements are verified, such as ball joint angle, CV joint angle, and clearance to surrounding parts to ensure no binding or interference. All products are hand tig welded by seasoned craftsmen. The quality fit and finish, ease of installation, and top shelf performance of these kits are what sets HCR Racing apart from the competition. No kits are released to the public without numerous hours of vigorous testing in the rocks, desert, and dunes for true dual sport application.


Materials

HCR Racing introduced a new proprietary material with the release of the Elite series suspension system. This unique custom alloy, created for the Elite series, produces unmatched strength while adding minimal weight. The custom alloy used in HCR's manufacturing process is 30% stronger in tensile and yield strength compared to 4130 series Chromoly. This custom material goes through several processes and is hardened for better wear resistance and overall strength. With hese higher tensile and yield strengths, HCR is able to product innovative designs without compromising strength and integrity by holding to HCR traditional internal box and ribbing methods.


Shocks

Feel confident in the demanding terrain with King HCR Race Series Shocks tuned by Bret King himself. The shocks provided with an HCR Complete suspension system are custom built to work specifically with the geometry of each kit. These custom HCR Series shocks are longer eye to eye and stroke, custom valved and sprung to achieve optimum performance without compromising motion ratio and minimizing shock fatigue. This allows for less compound leverage on the arm preventing further bottoming and damage to components. The KING HCR Series are true off-road shocks with larger internals than a competing UTV shock; providing minimal added weight without compromising performance. Backed by KING, HCR provides a 3 month tuning opportunity to meet with a KING Technician for a live testing session if a different valving option is preferred. Most custom shocks will be available in HCR Edition black and Silver at no extra charge.





Axles

HCR recently Partnered with RCV performance through the release of the YXZ Long Travel Kit. HCR has been working closely with RCV to provide the strongest axle options on the market, boasting twice the strength of a Factory axles. RCV Custom HCR Axle bars will be included and heavy duty assemblies will be available as an upgrade. RCV's Revolutionary axle shaft design provides the strength, smoothness, and reliability you need to power through the most demanding off road conditions.These new axles are included in the XP1000 Long Travel kit, Teryx Long Travel kit, Maverick XDS long Travel kit and XP900 Long Travel kit as well.
