HCR Racing Duner Suspension Kit for Can-Am Maverick X3 72"

Features:

• High-clearance boxed front A-arms and high-clearance rear trailing arms provide 1.25” of added ground clearance

• Laser-cut construction for precise fit and finish

• Chromoly mounting points for increased structural integrity

• Manufactured with HCR Elite Alloy, 30% stronger than 4130 chromoly

• TIG-welded by hand for strength and aesthetics

• Strategic cutouts reduce unsprung weight by more than 10% compared to our Dual Sport suspension without sacrificing strength

• Improved approach angles reduce surface attraction and friction

Description:

HCR’s Can-Am Maverick X3 Duner Suspension Kit uses high-clearance A-arm and trailing arm design to increase ground clearance 1.5 inches. Approach angles have been improved to reduce surface attraction and friction. This suspension kit is manufactured with HCR’s proprietary elite material. This custom alloy is 30% stronger in yield and tensile strength than 4130 chromoly and goes through several treatments to improve wear resistance and overall strength.

Duner Design for Less Unsprung Weight

Our Duner A-arms and trailing arms look great and the strategic cutouts lower overall suspension weight compared to our Dual Sport suspension. Less unsprung weight means quicker articulation over obstacles and chop. With quicker articulation, your tires spend more time on the ground, so you get more grip and control.

Improved Shock Tower

HCR includes an upgraded shock tower with your suspension upgrades. Enhanced durability supports your shocks, providing improved rigidity all around.

Upgrade to Keller Ball Joints

Get the most out of your Dual Sport A-arms with upgraded ball joints. Upgrade to Keller Ball Joints. They use a two-piece design to make it virtually impossible to rip out.

Keller Ball Joints

• 4340 hardened chromoly steel construction

• Two-piece threaded design doesn’t require a snap ring

• Easily adjustable, rebuildable, and greaseable

• Robust boot retaining ring prevents water intrusion

Kit Includes:

• 4 front A-arms (2 upper, 2 lower)

• 2 rear trailing arms

• Front Delrin bushing kit

• Brake line mounting hardware

• Shock bolts

Fitment:

Can-Am Maverick X3 X RC Turbo R : 2018-2020
Can-Am Maverick X3 X RC Turbo RR : 2020-2021
Can-Am Maverick X3 X RS Turbo R : 2017-2020
Can-Am Maverick X3 RS Turbo R : 2021
Can-Am Maverick X3 X RS Turbo RR : 2020-2021
Can-Am Maverick X3 X MR Turbo R : 2018-2019
Can-Am Maverick X3 X MR Turbo RR : 2020-2021
Can-Am Maverick X3 MAX X RS Turbo : 2017-2020

Can-Am Maverick X3 MAX X RS Turbo R : 2018-2020
Can-Am Maverick X3 MAX RS Turbo R : 2021
Can-Am Maverick X3 MAX X RS Turbo RR : 2020-2021
Can-Am Maverick X3 MAX X MR Turbo R : 2019-2021
Can-Am Maverick X3 MAX X RS Turbo RR w/ Smart-Shox 72 : 2022+
Can-Am Maverick X3 MAX X MR Turbo RR 72 : 2022+

Can-Am Maverick X3 X RS Turbo RR w/ Smart-Shox 72 : 2022+
Can-Am Maverick X3 X RC Turbo RR 72 : 2022+
Can-Am Maverick X3 X MR Turbo RR 72 : 2022+
Can-Am Maverick X3 MAX RS Turbo RR 72 : 2022+
Can-Am Maverick X3 MAX X RS Turbo RR 72 : 2022+

Can-Am Maverick X3 MAX X MR Turbo RR : 2020-2021
Can-Am Maverick X3 MAX X DS Turbo RR : 2020-2021
Can-Am Maverick X3 RS Turbo RR 72 : 2022+
Can-Am Maverick X3 X RS Turbo RR 72 : 2022+

Special Notes:

• Will not fit 14” wheels

• Must reuse or replace OEM trailing arm radial bearings, front ball joints, crush sleeves, wear plates, mounting bolts, and other hardware

• HCR kits are made to order. Quality takes time
